• SF cube cell analysis technology for WBC.
• Reticulocyte & NRBC flag detection.
• Provides dedicated flag called “ Infected RBC” ( Malaria screening).
• PLT- Optical + fluorescence measurement.

Principles:

SF cube cell analysis technology for WBC 5-part diff, NRBC, RET and PLT-O.

Focusing flow-DC method for RBC and PLT.

Cyanide free hemoglobin measurement.

Parameters:

33 reportable parameters: WBC, Lym%, Mon%, Neu%, Bas%, Eos%, Lym#, Mon#, Neu#,

Eos#, Bas#; RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, RET%, RET#, IRF, LFR,

MFR, HFR, NRBC#, NRBC%; PLT, MPV, PDW, PCT, P-LCR, P-LCC

14 research parameters: HFC#, HFC%, IMG#, IMG%, WBC-R, WBC-D, WBC-B, WBC-N,

RBC-O, PLT-O, PLT-I, PDW-SD, InR#, InR‰

2 histograms for RBC and PLT

3 scattergrams (3D) for DIFF, NRBC and RET

6 scattergrams (2D) for DIFF, BASO, NRBC, RET, RET-EXT, PLT-O

Performance:

Parameters	Linearity	Precision	Carryover
WBC	0-500x 109/L	<= 2.5% (>= 4x 109/L)	<=1.0%
RBC	0-8x 1012/L	<= 1.5% (>= 3.5x 1012/L)	<=1.0%
HGB	0-250g/L	<= 1.0% (110x180g/L)	<=1.0%
HCT	0-75%	<= 1.5% (30%-50%)	<=1.0%
PLT	0-5000x 109/L	<= 4.0% (>= 100x 109/L)	<=1.0%
RET#	0-0.8x 1012/L	<= 15% (RBC >= 3x 1012/L; 1% <= RET % <=4%)	/

Sample Volume:

Predilute mode (capillary blood), open vial   40ul.

Manual mode (whole blood), open vial 150ul.

Autoloader mode (whole blood), closed vial 200ul.

Throughput:

Up to 125 samples per hour (CBC+DIFF).

Up to 90 samples per hour (CBC+DIFF+RET).

Loading Capacity:

Up to 100 sample tubes.

Mode:

CBC, CBC+DIFF, CBC+RET, CBC+NRBC, CBC+DIFF+RET, CBC+DIFF+NRBC, CBC+DIFF+RET+NRBC, RET

Data Storage Capacity:

Up to 100,000 results including numeric and graphical information.

Printout:

Various formats and user-defined formats available.

Operating Environment:

Temperature: 15^oC ~ 30^oC

Humidity: 30~ 85%

Weight <= 125kg
